Splitter 8CH

DMX 8CH DMX Signal Amplifier 8 Way Distributor Stage Light 8 Output Ports Controller Dimmer Signal Optical Isolation Splitter

Input and output optical isolation, 8CH output signal amplification shaping capabilities extend signal output from the data line to enhance the ability to access the number of devices. Protection DMX512 lighting console output interface failure site isolation, improve digital lighting control system security and reliability.

– 8 channels DMX Splitter used the latest optical isolation technology, achieve the international advanced level. Protect each Channel work separately with optical isolation

– Built in 3 large independent transformers for each input and output channel.

– Eight optical isolation signal amplification to expand DMX signal output.

– Amplification function can make the connection extended over the standard DMX512 length.

– Deft appearance, firm structure, reduce the problem to happen again.

– Usually use with Programmable light, LED light, and lighting console.

Technical parameter

– Power supply: AC110V-240V, Frequency 50Hz -60Hz.

– Signal input interface: International standard DMX512 signal, 3 pin metal XLR male and female socket in parallel.

– Output signal interface: 3 pin metal XLR female socket.

– External interface all using metal joints!

– Packing size: 53*23*12cm

– Gross Weight: 3.3 KG
